About this vehicle
Description
POWERTECH AC
MOTOR: 48-volt AC Motor
OUTPUT RATING: 6.7 hp (5.0 kW)
MOTOR CONTROL UNIT: Toyota® Industries-built motor controller unit.
BATTERIES: Standard: Six 8-Volt Trojan® T875
Optional: Eight 6-Volt Trojan® T105 or Six 8-Volt Trojan T875 AGM
CHARGER: Delta-Q Charger
DIMENSIONS
OVERALL LENGTH 3250 mm (128 in)
OVERALL WIDTH 1200 mm (47.2 in)
OVERALL HEIGHT
(with suntop)
1910 mm (75.2 in)
OVERALL HEIGHT
(without suntop)
1222 mm (48.1 in)
WHEELBASE 2492 mm (98.1 in)
FRONT WHEEL TREAD 870 mm (34.3 in)
REAR WHEEL TREAD 980 mm (38.6 in)
MINIMUM GROUND CLEARANCE 148 mm (5.8 in)
FLOOR BOARD HEIGHT 342 mm (13.5 in)
PERFORMANCE
MAXIMUM FORWARD SPEED 19.0 mph (31 km/h)
MINIMUM TURNING RADIUS 9.2 ft (2.8 m)
GENERAL
DRY WEIGHT 349 kg (767 lbs) w/o suntop and batteries 519 kg (1144 (lbs) w/ Trojan T-875 batteries
TIRE SIZE 205/65-10 DOT (4-ply rating)
SEATING CAPACITY 4 persons
AVAILABLE MODEL COLORS Glacier, Emerald, Tanzanite, Sandstone Metallic, Moonstone Metallic, Onyx Metallic, Jasper Metallic
AVAILABLE SEAT COLOR Standard: Stone Optional: Black
AVAILABLE SUNTOP COLOR Stone, White, Black
DRY WEIGHT349 kg (767 lbs) w/o suntop and batteries 519 kg (1144 (lbs) w/ Trojan T-875 batteries
TIRE SIZE 205/65-10 DOT (4-ply rating)
SEATING CAPACITY 4 persons
AVAILABLE MODEL COLORS Glacier, Emerald, Tanzanite, Sandstone Metallic, Moonstone Metallic, Onyx Metallic, Jasper Metallic
AVAILABLE SEAT COLOR Standard: Stone Optional: Black
AVAILABLE SUNTOP COLOR Stone, White, Black
WARRANTY
Standard 2-year limited vehicle warranty.
